Elac Vertex 1 IC-V81-W (Each)

41,990.00

 Speaker type: 2-way, rear side open – Tweeter: 1-inch soft dome – Woofer: 8-inch polypropylene
cone Crossover frequency: 2,800 Hz Frequency response: 40 to 20,000 Hz
Sensitivity: 90 db at 2.83 v/1m
Recommended amplifier power: 30 to 120 wpc Nominal/peak power handling: 50/120 wpc Nominal impedance: 6 Ohm
Dimensions (diameter): 11.22 in / 285 mm Cut-out (diameter): 10.00 in / 254 mm Mounting depth: 4.48 in / 114 mm

We understands the importance of having audio to enhance a living space, with minimal aesthetic intrusion. With a slim profile, the easily installed Vertex in-ceiling speakers expand the line of our Integrator Series of custom products. Keeping our philosophy of delivering high-end sound, the Vertex series of speakers will compliment any conventional floorstanding or bookshelf loudspeaker.



KEY FEATURES

CUSTOM SILK-DOME TWEETER

Custom silk dome tweeters have been developed for low mass and smooth, extended high frequency response

CUSTOM-DESIGNED WOOFER WITH POLYPROPELYNE CONE

Polypropylene is employed due to its improved internal damping and smooth high frequency roll-off

INTRICATE CROSSOVER

A custom multi-element crossover with audio-grade components is implemented to ensure smooth transition between the drivers

SLIM PROFILE

A slim profile paintable magnetic grill allows for the speaker to virtually disappear in the room

ACCESSORY PRODUCTS

Optional square grill adapter is available to cosmetically match square lighting. Optional pre-construction bracket is available to aid in installation or use in ceiling tile applications.

  • Speaker type:2-way, rear side open
  • Tweeter:1 x 1-inch soft dome
  • Woofer:1 x 8-inch polypropylene cone
  • Crossover frequency:2,800 Hz
  • Frequency response:40 to 20,000 Hz
  • Sensitivity:90 db at 2.83 v/1m
  • Recommended amplifier power:30 ” 120 wpc
  • Nominal/peak power handling:50/120 wpc
  • Nominal impedance:6 Ohm
  • Binding posts:Metal spring terminals
  • Finish:Black baffle/White grille
  • Grille:Metal magnetic / Paintable
  • Accessories included:Cutout template, manual
  • Dimensions (diameter):11.22 in / 285 mm
  • Cut-out (diameter):10.00 in /254 mm
  • Mounting depth:4.48 in / 114 mm
Brand

Elac

Variant

Vertex Series 1

Product Type

In Ceiling Speaker

The Life of Sound. Backed by 95 Years of Excellence
SKU: IC-V81-W Category:
