Sound loudspeaker with 100 V line transformer and low impedance
Supported by our extensive experience in the sound sector, FONESTAR has created SONORA.
SONORA is a series of loudspeakers specially designed for public address and ambient sound applications.
Its excellent finish and elegant design allow a perfect integration into any space.
They are fully prepared for outdoor use as they have aluminum grille and protection against water (IP-66) and marine environments.
In addition, SONORA provides great sound quality, defined and without distortion.
They include all the necessary accessories for quick and easy installation: weather-treated swivel fixing bracket, stainless steel screws and steel safety cable.
For public address and ambient sound applications in public places such as restaurants, cafes, supermarkets, shopping malls, etc.
CHARACTERISTICS: | Sound loudspeaker with 100 V line transformer and low impedance. |
Prepared for outdoor use, protection against water and anti-corrosion materials. | |
POWER: | 80 W maximum, 40 W RMS |
SPEAKERS: | 1 polypropylene woofer 5 1/4” 1 tweeter 1” |
ANSWER: | 80-20,000 Hz |
IMPEDANCE: | 40 W RMS@100 V (250 Ω) 20 W RMS@100 V (500 Ω) 10 W RMS@100 V (1,000 Ω) 5 W RMS@100 V (2,000 Ω) |
Low Z: 8 Ω | |
SENSITIVITY: | 86 dB @ 1 W/1 m |
MAXIMUM SOUND PRESSURE : | 99 dB @ max. W/1 m |
COVERAGE ANGLE: | H/V: 200º/200º@500Hz, 135º/135º@1kHz, 100º/120º@2kHz, 60º/80º@4kHz (-6 dB) |
PROTECTIONS: | IP-66 according to EN 60529 |
IEC 60068-2-11 Environmental Testing (Salt Spray) | |
MATERIAL: | ABS |
Aluminum | |
Grating Weatherproof | |
Bracket Stainless Steel Screws | |
SWITCH: | W selector at high Z and low Z |
CONNECTORS: | Euroblock inlet and outlet for cable 0.25 – 2.5 mm² cross-section |
TEMPERATURE RANGE: | -10ºC ~ 60ºC |
COLOUR: | White (RAL 9003) |
MEASUREMENT: | Speaker: 162 x 263 x 147 mm D |
Wall plate bracket: 68 x 110 mm Speaker with stand: 216 mm | |
deep | |
WEIGHT: | 2.2 kg |
ACCESSORIES: | Fixing bracket that can be swivel ± 60° in all directions |
Steel safety cable |
