706 S3

280,000.00

Thanks to 706 S3’s decoupled Carbon Dome tweeter and carefully upgraded crossover, it provides exceptional detail and insight into your music, while its substantial 165mm (6.5in) Continuum Cone bass/midrange drive unit provides ample scale and extension for use in larger spaces.

Sharper detail

Carbon Dome tweeters are purpose-built for the 700 Series. Delivering a dramatic improvement on the aluminium double dome tweeter, they raise the breakup threshold to 47kHz, for pinpoint imaging accuracy and detail.

Truly amazing sound

Thanks to its composite construction, the Continuum™ cone avoids the abrupt transitions in behaviour that can impair the performance of a conventional drive unit. The result is a more open, neutral performance that delivers voices and instruments with precision and transparency.

Inspired by greatness

The new curved cabinet baffle and individual drive unit pods are inspired by the 800 Series Diamond, and greatly reduce cabinet coloration, ensuring a cleaner, more immersive sound.

Specifications

  • Size & weight

    Dimensions Height: 345 mm (13.6 in) cabinet only
    Width: 192 mm (7.6 in) cabinet only
    Depth: 297 mm (11.7 in) cabinet only
    334 mm (13.1 in) including grille and terminals
    Net weight 8.42kg (18.6 lb)

    Technical details

    Technical features Decoupled Carbon Dome tweeter
    Continuum™ cone bass / midrange
    Flowport™
    Description 2-way vented-box system
    Drive units 1x ø25mm (1 in) Decoupled Carbon Dome high-frequency
    1x ø165mm (6.5 in) Continuum cone bass / midrange
    Frequency range 45Hz and 33kHz
    Frequency response 50Hz – 28kHz ±3dB
    Sensitivity 88dB spl (2.83Vrms, 1m)
    Harmonic distortion 2nd and 3rd harmonics (90dB, 1m on axis)
    <1% 100Hz – 22kHz
    <0.5% 150Hz – 20kHz
    Nominal impedance 8Ω (minimum 3.7Ω)
    Recommended amplifier power 30W – 120W into 8Ω on unclipped programme
    Max recommended cable impedance 0.1Ω

    Finishes

    Cabinet finishes Gloss Black
    Satin White
    Mocha
    Rosenut (APAC only)
    Grille finishes Black
    Grey (Satin White only)
Brand

Variant

Product Type

Loved by people who love music

SKU: 706-s3 Category:
