Elac Debut Reference DCR-52

Debut Reference Center Channel

Black Baffle with Walnut Cabinet
Debut Reference DCR52 Center Speaker
Enter the realm of extraordinary sound with the ELAC Debut Reference Center Channel Speaker. This pinnacle of audio engineering redefines the essence of clarity and precision in home theater setups. Crafted with meticulous attention to detail, this center channel speaker embodies acoustic excellence. Designed to complement the Debut Reference series, it serves as the anchor for immersive audio experiences, delivering crystal-clear dialogue and immersive soundscapes. Immerse yourself in cinematic realism as the ELAC Debut Reference Center Channel Speaker elevates your entertainment, bringing every whisper and thunderous roar to life with unparalleled fidelity and depth.

Improved High Frequency Response
An innovative waveguide, coupled with a redesigned, more open grill design, improves the upper high frequency response of the Debut Reference’s 1” soft-dome tweeter.

Full Perimeter Bracing
A newly implemented full perimeter brace, connecting the top, bottom, and side panels, effectively reduces cabinet vibrations, resulting in minimized audio coloration within the cabinet.

Cast Chassis Woofer
The recently developed cast chassis woofer enhances stiffness, reinforcing the front baffle and effectively minimizing resonances within the chassis and cabinet. Paired with our custom aramid cone that offers even greater stiffness and damping, far superior to polypropylene or paper.

Dual Flared Slot Port
The newly introduced dual flared slot vent enables enhanced bass dynamics by delivering higher bass output with reduced noise levels.

Premium Finishes
Debut Reference showcases premium finishes, offering a Walnut cabinet paired with a black painted front baffle, or an Oak cabinet complemented by a white painted front baffle ensuring these speakers blend seamlessly into any home decor, making a statement without taking up unnecessary space.

Features
Specifications
Resources
Height × Width × Depth 185 × 527 × 242 mm
Weight 10.1 Kg
Enclosure Type 2-Way Bass Reflex
Frequency Response 55Hz – 35000Hz
Nominal Impedance 8 Ω
Sensitivity 87dB @ 2.83v/1m
Crossover Frequency 2200Hz
Max Power Input 120 Watts
Tweeter 1” Soft Dome
Woofer 2 x 5-1/4” Aramid Fiber
Cabinet CARB2 Rated MDF
Port 2 × Dual Flared
Binding Posts 5-Way Metal
Cabinet Finish White Baffle / Oak Cabinet or Black Baffle / Walnut Cabinet
